Features
- Label printing, the label out, one time finished, can also use even printing or label out.
- Printing position, direction adjustable, with scale for easy recording, adjustment, setting.
- Can be printed 1-2 lines, one line can be placed up to 14 digitals. ◎ Has warning device of ribbon shortage, which can effectively prevent the leakage printing.
- Use the ribbon cartridge printing, printing fine, maintenance-free and low cost.
- Using closed-loop temperature control device , heating fast and stable.
- Automatic have label out & printing, the label length is adjustable.
- Detected by electric eye to control movement in accurate action.
- Parallel rows workable for small labels, meanwhile peel, production capacity be doubled.
- With 5-digit counting display.
- Totally Stainless-steel material.
- Speed: 30~60pcs/min.
Specification
| Model |
EASY-PLS302A |
| Power |
110V/220V 50/60Hz |
| Printing area |
4mm x 28mm /one line
8mm x 28mm/two lines(standard)
16mm x8mm/three lines
|
| Applicable ribbon |
6060-B |
| Size of letters |
2mm x 4mmH(Cu) |
| Machine weight |
11Kg |
| Machine size |
360L x 280W x 500H(mm)
|
| Label size |
L 10 ～200mm W10 ～ 200mm |
| Paper tube size |
Internal diameter 36mm up |
| Under external diameter |
200mm |
|
|
